| Onderdeel nommer | N140JCN-GS9 |
| Handelsmerk | Innolux |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 1920×1200 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | Innolux |
| model | N140JCN-GS9 (CMN1417) |
| diagonale grootte | 14.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 161PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 301.594(H)×188.496(V) mm |
| buitelyn dof. | 306.59(H)×198.6(V) ×4.5(D) mm |
| ring area | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 16/14 (Typ.)(Tr/Tf) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | AAS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 100% sRGB |
| Ligbron | WLED , 15K hours , With LED Driver |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | On-Cell Touch |
| koppelvlak tipe | eDP (2 Lanes) , eDP1.4 , 40 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
