| Onderdeel nommer | N140BGA-EB4 |
| Handelsmerk | Innolux |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| handelsmerk | Innolux |
| model | N140BGA-EB4 (CMN14E3) |
| diagonale grootte | 14.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1366(RGB)×768 [WXGA] 112PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 309.399(H)×173.952(V) mm |
| buitelyn dof. | 315.9(H)×197.53(V) ×3(D) mm |
| ring area | - |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| helderheid | 220 cd/m² (Typ.) |
| kontras verhouding | 600:1 (Typ.) (TM) |
| kyk rigting | 6 o'clock |
| reaksie tyd | 3/7 (Typ.)(Tr/Td) |
| kykhoek | 45/45/20/45 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K 45% NTSC |
| Ligbron | WLED [10S3P] , 15K hours , With LED Driver |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| ontwerp vir | Laptop |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
