| Onderdeel nommer | N080JCE-G41 Rev.A1 |
| Handelsmerk | Innolux |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| paneel handelsmerk | Innolux |
| paneel model | N080JCE-G41 Rev.A1 |
| paneel grootte | 8.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1200(RGB)×1920, WUXGA, 283PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 107.64(W)×172.224(H) mm |
| ring opening | - |
| omtrek grootte | 114.6(W)×184.6(H) ×3.65(D) mm |
| oppervlak | Glare (Haze 0%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | AAS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 60% NTSC |
| tipe lamp | WLED , 15K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 80.0g (Max.) |
| aansoek | Pad & Tablet |
| sein koppelvlak | MIPI (4 data lanes) , 45 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
