| Onderdeel nommer | MV238QHB-N10 |
| Handelsmerk | BOE |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor |
| Resolusie | 2560×1440 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE |
| paneel model | MV238QHB-N10 |
| paneel grootte | 23.8" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 2560(RGB)×1440, Quad-HD, 123PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 526.848(W)×296.352(H) mm |
| ring opening | - |
| omtrek grootte | 534.84(W)×308.16(H) ×1.32(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | ADS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| deurlaatbaarheid | - |
| kleure vertoon | 16.7M 100% sRGB |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COF Built-in 8 source chips |
| paneel gewig | TBD |
| aansoek | Desktop Monitor |
| sein koppelvlak | LVDS (4 ch, 8-bit) , 70 pins Connector |
| insetspanning | 5.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
