| Onderdeel nommer | MV230FHB-N40 |
| Handelsmerk | BOE |
| Grootte | 23.0 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | BOE |
| model naam | MV230FHB-N40 |
| skerm grootte | 23.0 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 95PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 509.184 × 286.416 (H×V) |
| buitelyn (mm) | 517 × 298.096 × 1.32 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000 : 1 (Min.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| deurlaatbaarheid | 5.3% (Typ.)(with Polarizer) |
| kleurdiepte | 16.7M NTSC |
| agterlig | No B/L |
| massa | 484g (Typ.) |
| gebruik vir | Desktop Monitor |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| bestuurder ic lys | Built-in COF 6 source chips |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LC230WX3-SLA1 | LG Display | 23.0 | 1366×768 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLL1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SSA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM230WFA-SLZ1 | LG Display | 23.0 | 1920×1080 |
| LTA230AP01 | Samsung | 23.0 | 1366×768 |
| LTA230W2-L01 | Samsung | 23.0 | 1366×768 |
| M230HGE-L20 | Innolux | 23.0 | 1920×1080 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
