| Onderdeel nommer | MV185WHB-N20 |
| Handelsmerk | BOE |
| Grootte | 18.5 |
| Toepassing | Desktop Monitor |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | BOE |
| model | MV185WHB-N20 |
| diagonale grootte | 18.5 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1366(RGB)×768 [WXGA] 84PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 409.8(H)×230.4(V) mm |
| buitelyn dof. | 422.2(H)×244.1(V) ×1.32(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | HADS, Normally Black, Transmissive |
| plaat dikte | 0.50+0.50 mm |
| oordrag | 6.0% (Typ.)(with Polarizer) |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | No B/L |
| gewig | 327g (Typ.) |
| ontwerp vir | Desktop Monitor |
| raamkoers | 60Hz |
| raakpaneel | Without |
| d-ic detail | COF Built-in 2 source chips |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
