| Onderdeel nommer | MG1561B01-2 |
| Handelsmerk | CSOT |
| Grootte | 15.6 |
| Toepassing | Digital Signage |
| Resolusie | 1920×1080 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | CSOT |
| model naam | MG1561B01-2 |
| skerm grootte | 15.6 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 141PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 344.16 × 193.59 (H×V) |
| buitelyn (mm) | 351.86 × 206.332 × 6.31 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 3000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | VA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | WLED , 15K hours , With LED Driver |
| massa | 530g (Typ.) |
| gebruik vir | Digital Signage |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 40 pins |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B156RW01 V0 | AUO | 15.6 | 1600×900 |
| B156XTT01.1 | AUO | 15.6 | 1366×768 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| G156XW01 V3 | AUO | 15.6 | 1366×768 |
| LP156WH8-TLA1 | LG Display | 15.6 | 1366×768 |
| LTN156AT05-H02 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT36-D01 | Samsung | 15.6 | 1366×768 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| NT156WHM-N33 | BOE | 15.6 | 1366×768 |
