| Onderdeel nommer | MCG156FDLAAQNN-AN20 |
| Handelsmerk | Kyocera |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1920×1080 |
| Samestelling | LTPS TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | Kyocera |
| paneel grootte | 15.6" |
| resolusie | 1920(RGB)×1080, FHD, 141PPI |
| vertoon area | 344.16(W)×193.59(H) mm |
| omtrek grootte | 363.8(W)×215.9(H) ×9.8(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.2M 73% NTSC |
| frekwensie | 60Hz |
| gewig | 1.05/1.09Kgs (Typ./Max.) |
| paneel model | MCG156FDLAAQNN-AN20 |
| paneel tipe | LTPS TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 347.06(W)×196.49(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | AWV, Normally Black, Transmissive |
| reaksie tyd | 13/12 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
