| Onderdeel nommer | M270HTN02.2 CELL |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | V-by-One |
| paneel handelsmerk | AUO |
| paneel grootte | 27.0" |
| resolusie | 1920(RGB)×1080, FHD, 81PPI |
| vertoon area | 597.6(W)×336.15(H) mm |
| omtrek grootte | 608.3(W)×349.3(H) ×1.5(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| glas diepte | 0.50+0.50 mm |
| kleure vertoon | 16.7M 71% NTSC |
| frekwensie | 144Hz |
| bestuurder ic | COF Built-in 6 source chips |
| paneel gewig | 665g (Typ.) |
| sein koppelvlak | V-by-One 8 lane , 40 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | M270HTN02.2 CELL |
| paneel tipe | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 3.8/1.2 (Typ.)(Tr/Td) |
| deurlaatbaarheid | 5.3% (Typ.)(with Polarizer) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | Desktop Monitor Gaming |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V1 | AUO | 27.0 | 1920×1080 |
