| Onderdeel nommer | M236HVR01.0 CELL |
| Handelsmerk | AUO |
| Grootte | 23.6 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel grootte | 23.6" |
| resolusie | 1920(RGB)×1080, FHD, 93PPI |
| vertoon area | 521.395(W)×293.285(H) mm |
| omtrek grootte | 532.995(W)×305.185(H) ×1.11(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| glas diepte | 0.40+0.40 mm |
| kleure vertoon | 16.7M 69% NTSC |
| frekwensie | 165Hz |
| gewig | 530g (Typ.) |
| paneel model | M236HVR01.0 CELL |
| paneel tipe | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare (Haze 40%), Hard coating (3H) |
| kontras verhouding | 3000:1 (Typ.) (TM) |
| vertoonmodus | VA, Normally Black, Transmissive |
| reaksie tyd | 20 (Typ.)(G to G) |
| deurlaatbaarheid | 3.22% (Typ.)(with Polarizer) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | Desktop Monitor Gaming |
