| Onderdeel nommer | M236HJJ-P02 Rev.C4 |
| Handelsmerk | Innolux |
| Grootte | 23.6 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| handelsmerk | Innolux |
| model | M236HJJ-P02 Rev.C4 |
| diagonale grootte | 23.6 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1920(RGB)×1080 [FHD] 93PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 521.28(H)×293.22(V) mm |
| buitelyn dof. | 534.28(H)×306.252(V) mm |
| ring area | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 3000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 20/5 (Typ.)(Tr/Td) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | Super MVA, Normally Black, Transmissive |
| plaat dikte | - |
| oordrag | 4.8% (Typ.)(with Polarizer) |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | No B/L |
| gewig | TBD |
| ontwerp vir | Desktop Monitor |
| raamkoers | 60Hz |
| raakpaneel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-P02 | Innolux | 23.6 | 1920×1080 |
| MV236FHB-N10 | BOE | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
