| Onderdeel nommer | M200HJJ-L20 Rev.B1 |
| Handelsmerk | Innolux |
| Grootte | 19.5 |
| Toepassing | Desktop Monitor Indu |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | 9S4P |
| Koppelvlak | LVDS |
| vervaardiger | Innolux |
| skerm grootte | 19.5 inch |
| pixel nommer | 1920(RGB)×1080 (FHD) 112PPI |
| aktiewe area (mm) | 434.88 × 238.68 (H×V) |
| ring area (mm) | 438.18 × 241.98 (H×V) |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 72% NTSC |
| massa | 1.47±0.08Kgs |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | M200HJJ-L20 Rev.B1 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 459.8 × 263 × 11.82 (H×V×D) |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| kontras verhouding | 3000 : 1 (Typ.) (TM) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| werksmodus | MVA, Normally Black, Transmissive |
| agterlig | 9S4P WLED , 30K hours , No Driver |
| gebruik vir | Desktop Monitor Industrial |
| raakskerm | Without |
