| Onderdeel nommer | M185XW01 V8 |
| Handelsmerk | AUO |
| Grootte | 18.5 |
| Toepassing | DMPC |
| Resolusie | 1366×768 |
| Samestelling | LCM |
| Helderheid | 200 |
| CR | 700:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | M185XW01 V8 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 18.5 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 409.8×230.4 mm |
| buitelyn | 430.37×254.6×11 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 200 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193165% |
| reaksie tyd | 3.6/1.4 (Typ.)(Tr/Td) |
| kykhoek | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (1 ch, 8-bit), 30 pins |
| insetspanning | 5.0V (Typ.) |
| aansoek | DMPC |
