| Onderdeel nommer | M101GWWC R5 |
| Handelsmerk | IVO |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 800×1280 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 7S4P |
| Koppelvlak | |
| vervaardiger | IVO |
| model naam | M101GWWC R5 |
| skerm grootte | 10.1 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 800(RGB)×1280 (WXGA) 150PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 135.36 × 216.58 (H×V) |
| buitelyn (mm) | 142 × 228.5 × 4.5 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 60% NTSC |
| agterlig | 7S4P WLED , 22K hours , No Driver |
| massa | 145g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
