| Onderdeel nommer | M101GW4G R0 |
| Handelsmerk | IVO |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 5S4P |
| Koppelvlak | MIPI |
| paneel handelsmerk | IVO |
| paneel grootte | 10.1" |
| resolusie | 1200(RGB)×1920, WUXGA, 225PPI |
| vertoon area | 135.36(W)×216.576(H) mm |
| omtrek grootte | 147.78(W)×232(H) ×4.8(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 67% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 155g (Max.) |
| sein koppelvlak | MIPI (4 data lanes) , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | M101GW4G R0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | 5S4P WLED , 22K hours , Without Driver |
| raakskerm | Without |
| aansoek | Pad & Tablet |
