| Onderdeel nommer | M090AWP4 R1 |
| Handelsmerk | IVO |
| Grootte | 9.0 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | Parallel |
| vervaardiger | IVO |
| skerm grootte | 9.0 inch |
| pixel nommer | 800(RGB)×480 (WVGA) 104PPI |
| aktiewe area (mm) | 198 × 112.08 (H×V) |
| ring area (mm) | 200.2 × 114.28 (H×V) |
| helderheid | 750 cd/m² (Typ.) |
| kykhoek | 70/70/50/70 (Typ.)(CR≥10) |
| goeie uitsig by | 6 o'clock |
| kleurdiepte | 262K 70% NTSC |
| massa | - |
| herlaaitempo | 60Hz |
| sein tipe | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| maks. graderings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| model naam | M090AWP4 R1 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 700 : 1 (Typ.) (TM) |
| reaksie | 12 (Typ.)(Tr+Td) ms |
| werksmodus | TN, Normally White, Transmissive |
| agterlig | WLED , No Driver |
| gebruik vir | Outdoor High Brightness Automotive Display |
| raakskerm | Without |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| T-55561D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| T-55562D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TM090JDH01 | Tianma | 9.0 | 1280×800 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
