| Onderdeel nommer | LTM238HP01 |
| Handelsmerk | SAMSUNG |
| Grootte | 23.8 |
| Toepassing | Desktop Monitor |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | SAMSUNG |
| model naam | LTM238HP01 |
| skerm grootte | 23.8 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 92PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 527.04 × 296.46 (H×V) |
| buitelyn (mm) | - |
| helderheid | - |
| kontras verhouding | 3000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | PVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | WLED |
| massa | - |
| gebruik vir | Desktop Monitor |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
