| Onderdeel nommer | LTI700HN02 |
| Handelsmerk | SAMSUNG |
| Grootte | 70 |
| Toepassing | Interactive Whiteboa |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | SAMSUNG |
| paneel grootte | 70" |
| resolusie | 1920(RGB)×1080, FHD, 31PPI |
| vertoon area | 1549.44(W)×871.56(H) mm |
| omtrek grootte | 1600(W)×922(H) ×51.9(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 72% NTSC |
| frekwensie | 60Hz |
| gewig | 31.0/33Kgs (Typ./Max.) |
| paneel model | LTI700HN02 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 1560(W)×882(H) mm |
| oppervlak | Antiglare (Haze 2.3%), Hard coating (2H) |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| vertoonmodus | S-PVA, Normally Black, Transmissive |
| reaksie tyd | 8 (Typ.)(G to G) |
| tipe lamp | WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Interactive Whiteboard |
