| Onderdeel nommer | LTI400HN01 |
| Handelsmerk | SAMSUNG |
| Grootte | 40 |
| Toepassing | Digital Signage |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SAMSUNG |
| paneel model | LTI400HN01 |
| paneel grootte | 40" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 55PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 885.6(W)×498.15(H) mm |
| ring opening | 891.6(W)×504.15(H) mm |
| omtrek grootte | 911.4(W)×523.95(H) ×22.4(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (2H) |
| helderheid | 700 cd/m² (Typ.) |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | SVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 16 (Typ.)(G to G) |
| kleure vertoon | 1.07B 100% sRGB |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 8.2Kgs (Max.) |
| aansoek | Digital Signage |
| sein koppelvlak | LVDS (2 ch, 10-bit) , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
