| Onderdeel nommer | LSM315DP01 |
| Handelsmerk | SAMSUNG |
| Grootte | 32.0 |
| Toepassing | Desktop Monitor Gami |
| Resolusie | 2560×1440 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 3000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| paneel handelsmerk | SAMSUNG |
| paneel grootte | 32.0" |
| resolusie | 2560(RGB)×1440, Quad-HD, 93PPI |
| vertoon area | 697.344(W)×392.256(H) mm |
| omtrek grootte | 708.944(W)×405.731(H) ×1.11(D) mm |
| helderheid | 0 cd/m² |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| glas diepte | 0.40+0.40 mm |
| kleure vertoon | 16.7M 69% NTSC |
| frekwensie | 144Hz |
| gewig | 900g (Typ.) |
| paneel model | LSM315DP01 |
| paneel tipe | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare (Haze 25%) |
| kontras verhouding | 3000:1 (Typ.) (TM) |
| vertoonmodus | PVA, Normally Black, Transmissive |
| reaksie tyd | 22 (Typ.)(G to G) |
| deurlaatbaarheid | 3.0% (Typ.)(with Polarizer) |
| tipe lamp | No B/L |
| raakskerm | Without |
| aansoek | Desktop Monitor Gaming |
