| Onderdeel nommer | LSI490HN01-V |
| Handelsmerk | SAMSUNG |
| Grootte | 49 |
| Toepassing | Digital Signage |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 4000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | SAMSUNG |
| model | LSI490HN01-V |
| diagonale grootte | 49 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 1920(RGB)×1080 [FHD] 45PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 1073.78(H)×604(V) mm |
| buitelyn dof. | 1083.78(H)×615.5(V) ×1.3(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 25%), Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 4000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 6 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | SPVA, Normally Black, Transmissive |
| plaat dikte | 0.40+0.50 mm |
| oordrag | 6.79% (Typ.)(with Polarizer) |
| ondersteun kleur | 1.07B 99% sRGB |
| Ligbron | No B/L |
| gewig | 1.80±0.18Kgs |
| ontwerp vir | Digital Signage |
| raamkoers | 60Hz |
| raakpaneel | Without |
| d-ic detail | COF Built-in 6 source chips |
| koppelvlak tipe | LVDS (2 ch, 10-bit) , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| HV490FHB-N80 | BOE | 49 | 1920×1080 |
| LC490DUJ-SGE3 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA2 | LG Display | 49 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| MT4851D01-1 | CSOT | 49 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
