| Onderdeel nommer | LSC550HN06-W |
| Handelsmerk | SAMSUNG |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | SAMSUNG |
| diagonale grootte | 55 inch |
| pixel formaat | 1920(RGB)×1080 [FHD] 40PPI |
| aktiewe area | 1209.6(H)×680.4(V) mm |
| ring area | - |
| helderheid | 0 cd/m² |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| plaat dikte | 0.40+0.50 mm |
| ondersteun kleur | 1.07B 99% sRGB |
| gewig | 2.33Kgs (Typ.) |
| raamkoers | 60Hz |
| d-ic detail | COF Built-in 6 source chips |
| koppelvlak tipe | LVDS (2 ch, 10-bit) , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC550HN06-W |
| tipe | a-Si TFT-LCD , CELL |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 1219.6(H)×692.9(V) ×1.3(D) mm |
| behandeling | Antiglare (Haze 2.3%), Hard coating (2H) |
| kontras verhouding | 5000:1 (Typ.) (TM) |
| reaksie tyd | 6 (Typ.)(G to G) |
| bedryfsmodus | SVA, Normally Black, Transmissive |
| oordrag | 7.0% (Typ.)(with Polarizer) |
| Ligbron | No B/L |
| ontwerp vir | TV Sets |
| raakpaneel | Without |
| LC550EUD-SCA2 | LG Display | 55 | 1920×1080 |
| LC550EUD-SEF3 | LG Display | 55 | 1920×1080 |
| LC550EUF-FFP2 | LG Display | 55 | 1920×1080 |
| LC550WUD-SBM4 | LG Display | 55 | 1920×1080 |
| LSC550FJ06-W01 | Samsung | 55 | 3840×2160 |
| LSC550FN05 | Samsung | 55 | 3840×2160 |
| LSC550FN06 | Samsung | 55 | 3840×2160 |
| LTI550FN01 | Samsung | 55 | 3840×2160 |
| LTI550HN11 | Samsung | 55 | 1920×1080 |
| V546H1-LS2 | Innolux | 55 | 1920×1080 |
