| Onderdeel nommer | LSC490HN05-W |
| Handelsmerk | SAMSUNG |
| Grootte | 49 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 6000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| handelsmerk | SAMSUNG |
| diagonale grootte | 49 inch |
| pixel formaat | 1920×1080(RGB) [FHD] 45PPI |
| aktiewe area | 1073.78(H)×604(V) mm |
| ring area | - |
| helderheid | 0 cd/m² |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| plaat dikte | - |
| ondersteun kleur | 16.7M 99% NTSC |
| gewig | 1.70Kgs (Typ.) |
| raamkoers | 60Hz |
| d-ic detail | COF Built-in 2 source chips |
| koppelvlak tipe | LVDS (2 ch, 10-bit) , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC490HN05-W |
| tipe | a-Si TFT-LCD , CELL |
| konfigurasie | RGB Horizontal Stripe |
| buitelyn dof. | 1078.78(H)×617.8(V) ×1.3(D) mm |
| behandeling | Antiglare (Haze 2.3%), Hard coating (2H) |
| kontras verhouding | 6000:1 (Typ.) (TM) |
| reaksie tyd | 8 (Typ.)(G to G) |
| bedryfsmodus | SVA, Normally Black, Transmissive |
| oordrag | 6.9% (Typ.)(with Polarizer) |
| Ligbron | No B/L |
| ontwerp vir | TV Sets |
| raakpaneel | Without |
| HV490FHB-N80 | BOE | 49 | 1920×1080 |
| LC490DUJ-SGE3 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA2 | LG Display | 49 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| MT4851D01-1 | CSOT | 49 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
