| Onderdeel nommer | LSC480HN08-W |
| Handelsmerk | SAMSUNG |
| Grootte | 48 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | SAMSUNG |
| model naam | LSC480HN08-W |
| skerm grootte | 48 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1920×1080(RGB) (FHD) 46PPI |
| reëling | RGB Horizontal Stripe |
| aktiewe area (mm) | 1054.08 × 592.92 (H×V) |
| buitelyn (mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 2.3%), Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 8 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | SVA, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| deurlaatbaarheid | 6.6% (Typ.)(with Polarizer) |
| kleurdiepte | 1.07B 68% NTSC |
| agterlig | No B/L |
| massa | 1.90Kgs (Typ.) |
| gebruik vir | TV Sets |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| bestuurder ic lys | Built-in COF 3 source chips |
| sein tipe | LVDS (2 ch, 10-bit) , Connector 51 pins |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
