| Onderdeel nommer | LS055R3SX01 |
| Handelsmerk | Sharp |
| Grootte | 5.5 |
| Toepassing | Mobile Phone |
| Resolusie | 1536×2560 |
| Samestelling | CG-Silicon , LCM |
| Helderheid | |
| CR | 1280:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | Sharp |
| diagonale grootte | 5.5 inch |
| pixel formaat | 1536(RGB)×2560 546PPI |
| aktiewe area | 71.424(H)×119.04(V) mm |
| helderheid | 460 cd/m² (Typ.) |
| kyk rigting | Symmetry |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 70% NTSC |
| gewig | 21.1g |
| raamkoers | 60Hz |
| koppelvlak tipe | MIPI (4 data lanes) , 32 pins Connector |
| kragtoevoer | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| omgewing | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | LS055R3SX01 |
| tipe | CG-Silicon , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 73.824(H)×126.44(V) ×1.4(D) mm |
| kontras verhouding | 1280:1 (Typ.) (TM) |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| bedryfsmodus | New Mode2, Normally Black, Transmissive |
| Ligbron | WLED [8S2P] , W/O Driver |
| ontwerp vir | Mobile Phone |
| raakpaneel | Without |
