| Onderdeel nommer | LS050T1SX18 |
| Handelsmerk | Sharp |
| Grootte | 5.0 |
| Toepassing | Mobile Phone |
| Resolusie | 1080×1920 |
| Samestelling | CG-Silicon, LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | 6S2P |
| Koppelvlak | MIPI |
| paneel handelsmerk | Sharp |
| paneel model | LS050T1SX18 |
| paneel grootte | 5.0" |
| paneel tipe | CG-Silicon, LCM |
| resolusie | 1080(RGB)×1920, FHD, 445PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 61.641(W)×109.584(H) mm |
| ring opening | - |
| omtrek grootte | 63.64(W)×116.224(H) ×1.16(D) mm |
| oppervlak | - |
| helderheid | 480 cd/m² (Typ.) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| vertoonmodus | New Mode2, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 35 (Max.)(Tr+Td) |
| kleure vertoon | 16.7M 95% NTSC |
| tipe lamp | 6S2P WLED , Without Driver |
| frekwensie | 60Hz |
| raakskerm | PCAP |
| paneel gewig | 14.0g (Typ.) |
| aansoek | Mobile Phone |
| sein koppelvlak | MIPI (4 data lanes) , 40 pins Connector |
| insetspanning | 1.8/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| omgewing | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
