| Onderdeel nommer | LQ800D3HA01 |
| Handelsmerk | Sharp |
| Grootte | 80 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 5000:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | LVDS |
| paneel handelsmerk | Sharp |
| paneel model | LQ800D3HA01 |
| paneel grootte | 80" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 1920(RGB)×1080, FHD, 27PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1771.2(W)×996.3(H) mm |
| ring opening | - |
| omtrek grootte | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 5000:1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| vertoonmodus | ASV, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 4 (Typ.)(G to G) |
| glas diepte | - |
| deurlaatbaarheid | 6.51% (Typ.)(with Polarizer) |
| kleure vertoon | 1.07B 73% NTSC |
| tipe lamp | No B/L |
| frekwensie | 120Hz |
| raakskerm | Without |
| bestuurder ic | COF Built-in 16 source + 10 gate chips |
| paneel gewig | 7.80g (Typ.) |
| aansoek | TV Sets |
| sein koppelvlak | LVDS (4 ch, 10-bit) , 92 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
