| Onderdeel nommer | LQ133T1JW01 |
| Handelsmerk | SHARP |
| Grootte | 13.3 |
| Toepassing | NBPC |
| Resolusie | 2560×1440 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | SHARP |
| paneel model | LQ133T1JW01 |
| paneel tipe | IGZO TFT-LCD , LCM |
| paneel grootte | 13.3 inch |
| resolusie | 2560(RGB)×1440 , Quad-HD |
| vertoonmodus | Normally Black, Transmissive |
| aktiewe area | 293.76×165.24 mm |
| buitelyn | 305.35×187.9×3.05 mm |
| vorm styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| oppervlak | Glare (Haze 0%), Hard coating (2H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit), CIE193172% |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | eDP (4 Lanes), 40 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
| LP133WF6-SSA1 | LG Display | 13.3 | 1920×1080 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LQ133K1LA4A | SHARP | 13.3 | 1280×800 |
| LQ133K1LD4B | SHARP | 13.3 | 1280×800 |
| LQ133M1JW03 | SHARP | 13.3 | 1920×1080 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW19 | SHARP | 13.3 | 2560×1440 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
| B141XG10 V0 | AUO | 14.1 | 1024×768 |
| B150XG02 V4 | AUO | 15.0 | 1024×768 |
| B154SW02 V0 | AUO | 15.4 | 1680×1050 |
| LP121WX3-TLB1 | LG Display | 12.1 | 1280×800 |
| LP154WE2-TLA7 | LG Display | 15.4 | 1680×1050 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP156WF1-TLF3 | LG Display | 15.6 | 1920×1080 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
| LTN173KT01-W01 | Samsung | 17.3 | 1600×900 |
| N140BGE-E43 | Innolux | 14.0 | 1366×768 |
