| Onderdeel nommer | LQ125M1JW31 |
| Handelsmerk | Sharp |
| Grootte | 12.5 |
| Toepassing | Laptop Pad & Tablet |
| Resolusie | 1920×1080 |
| Samestelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | Sharp |
| paneel grootte | 12.5" |
| resolusie | 1920(RGB)×1080, FHD, 176PPI |
| vertoon area | 276.48(W)×155.52(H) mm |
| omtrek grootte | 282.08(W)×169.49(H) ×4.6(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 100% sRGB |
| frekwensie | 60Hz |
| vorm styl | Slim (PCBA Bent, T≤3.0mm) |
| sein koppelvlak | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
| paneel model | LQ125M1JW31 (SHP144F) |
| paneel tipe | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Hard coating (3H) |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| vertoonmodus | New Mode2, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Laptop Pad & Tablet |
