| Onderdeel nommer | LQ121X3LH01 |
| Handelsmerk | SHARP |
| Grootte | 12.1 |
| Toepassing | NBPC |
| Resolusie | 1024×768 |
| Samestelling | LCM |
| Helderheid | |
| CR | |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SHARP |
| paneel model | LQ121X3LH01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 12.1 inch |
| resolusie | 1024(RGB)×768 , XGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 245.76×184.32 mm |
| oppervlak | Antiglare |
| helderheid | |
| kontras verhouding | |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | |
| kykhoek | |
| tipe lamp | WLED |
| sein koppelvlak | LVDS (1 ch, 6-bit) |
| rohs: | |
| aansoek | NBPC |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| LQ121S1DG41 | SHARP | 12.1 | 800×600 |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| LQ121S1LG61 | SHARP | 12.1 | 800×600 |
| LQ121S1LG73 | SHARP | 12.1 | 800×600 |
| LQ121S1LG75 | SHARP | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| LQ121X1LH22 | SHARP | 12.1 | 1024×768 |
| LQ121X3LH01 | SHARP | 12.1 | 1024×768 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| B154SW02 V3 | AUO | 15.4 | 1680×1050 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LP140WH2-TLL2 | LG Display | 14.0 | 1366×768 |
| LP171WP4-TL03 | LG Display | 17.1 | 1440×900 |
| LTN140AT26-L01 | Samsung | 14.0 | 1366×768 |
| LTN156AT02-A04 | Samsung | 15.6 | 1366×768 |
| N154I2-L02 | Innolux | 15.4 | 1280×800 |
