| Onderdeel nommer | LQ080M1SX01 |
| Handelsmerk | Sharp |
| Grootte | 8.0 |
| Toepassing | Pad & Tablet |
| Resolusie | 1200×1920 |
| Samestelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleure | 16.7M |
| Agterlig | 5S5P |
| Koppelvlak | |
| paneel handelsmerk | Sharp |
| paneel grootte | 8.0" |
| resolusie | 1200(RGB)×1920, WUXGA, 284PPI |
| vertoon area | 107.28(W)×171.648(H) mm |
| omtrek grootte | 112.38(W)×182.75(H) ×3.19(D) mm |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 90% NTSC |
| frekwensie | 75Hz |
| gewig | 67g (Max.) |
| paneel model | LQ080M1SX01 |
| paneel tipe | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Clear, Hard coating |
| kontras verhouding | 1500:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 30 (Typ.)(Tr+Td) |
| tipe lamp | 5S5P WLED , 15K hours , Without Driver |
| raakskerm | Without |
| aansoek | Pad & Tablet |
