| Onderdeel nommer | LQ050A5AG03 |
| Handelsmerk | Sharp |
| Grootte | 5.0 |
| Toepassing | Automotive Display |
| Resolusie | 320×234 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 60:1 |
| Kleure | Full |
| Agterlig | 1 |
| Koppelvlak | Analog |
| vervaardiger | Sharp |
| model naam | LQ050A5AG03 |
| skerm grootte | 5.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 320(RGB)×234 79PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 102.124 × 74.763 (H×V) |
| buitelyn (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antireflection |
| helderheid | 320 cd/m² (Typ.) |
| kontras verhouding | 60 : 1 (Typ.) (TM) |
| kykhoek | 65/65/40/65 (Typ.)(CR≥5) |
| reaksie | 30/50 (Typ.)(Tr/Td) ms |
| goeie uitsig by | - |
| werksmodus | TN, Normally White, Transmissive |
| kleurdiepte | Full color |
| agterlig | 1 pcs CCFL , 10K hours , No Driver |
| massa | 180g (Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | - |
| raakskerm | Without |
| sein tipe | Analog RGB , Connector 22 pins |
| spanningstoevoer | 8.0/-5.0V (Typ.)(VSH/VSL) |
| maks. graderings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
