| Onderdeel nommer | LPM035M407B |
| Handelsmerk | JDI |
| Grootte | 3.5 |
| Toepassing | HMD VR AR |
| Resolusie | 1440×1600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | JDI |
| model | LPM035M407B |
| diagonale grootte | 3.5 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1440(RGB)×1600 615PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 59.4(H)×66(V) mm |
| buitelyn dof. | 62.2(H)×73.6(V) mm |
| ring area | - |
| behandeling | Hard coating |
| kyk rigting | Symmetry |
| reaksie tyd | - |
| kykhoek | - |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M |
| Ligbron | WLED [5S2P] |
| gewig | 17.0g (Typ.) |
| ontwerp vir | HMD VR AR |
| raamkoers | 90Hz |
| raakpaneel | Without |
| koppelvlak tipe | MIPI (4 data lanes) |
| kragtoevoer | 1.8/5.7/-5.7V (Typ.)(VDDI/AVDD/AVEE) |
| omgewing | Operating Temperature: -10 ~ 55 °C ; Storage Temperature: -20 ~ 70 °C |
