| Onderdeel nommer | LP173WF5-SPZ1 |
| Handelsmerk | LG Display |
| Grootte | 17.3 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | LG Display |
| paneel grootte | 17.3" |
| resolusie | 1920(RGB)×1080, FHD, 127PPI |
| vertoon area | 381.888(W)×214.812(H) mm |
| omtrek grootte | 389.89(W)×238.31(H) ×3.5(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (MIn.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.2M 72% NTSC |
| frekwensie | 60Hz |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| sein koppelvlak | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | LP173WF5-SPZ1 (LGD063B) |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Laptop |
