| Onderdeel nommer | LP140WF1-SPJ1 |
| Handelsmerk | LG Display |
| Grootte | 14.0 |
| Toepassing | NBPC |
| Resolusie | 1920×1080 |
| Samestelling | LCM |
| Helderheid | 300 |
| CR | 700:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | LG Display |
| paneel model | LP140WF1-SPJ1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 14.0 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | AH-IPS, Normally Black, Transmissive |
| aktiewe area | 309.31×173.99 mm |
| buitelyn | 320.4×205.1×3 mm |
| vorm styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| oppervlak | Glare (Haze 0%) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 700:1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193160% |
| reaksie tyd | 35 (Typ.)(Tr+Td) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | WLEDEmbedded (LED Driver) |
| sein koppelvlak | eDP (2 Lanes), 30 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | NBPC |
