| Onderdeel nommer | LP133WH2-SPB6 |
| Handelsmerk | LG Display |
| Grootte | 13.3 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 600:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| vervaardiger | LG Display |
| model naam | LP133WH2-SPB6 (LGD052E) 9 Compatible |
| skerm grootte | 13.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1366(RGB)×768 (WXGA) 118PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 293.42 × 164.97 (H×V) |
| buitelyn (mm) | 306.3 × 195.2 × 2.85 (H×V×D) |
| ring area (mm) | 296.45 × 168.3 (H×V) |
| behandeling | Antiglare |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 600 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 35 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 262K 45% NTSC |
| agterlig | WLED , 12K hours , With LED Driver |
| omtrek vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruik vir | Laptop |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (1 Lane) , HBR1 (2.7G/lane) , Connector 30 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LP133WD1-SLA1 | LG Display | 13.3 | 1600×900 |
| LP133WH2-TLE1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLHA | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LP133WP1-TJAA | LG Display | 13.3 | 1440×900 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LP133WX1-TLN3 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
