| Onderdeel nommer | LP116WH8-SPA1 |
| Handelsmerk | LG Display |
| Grootte | 11.6 |
| Toepassing | Laptop |
| Resolusie | 1366×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| vervaardiger | LG Display |
| model naam | LP116WH8-SPA1 (LGD0500) |
| skerm grootte | 11.6 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1366(RGB)×768 (WXGA) 135PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 256.125 × 144 (H×V) |
| buitelyn (mm) | 278 × 168 × 3.2 (H×V×D) |
| ring area (mm) | 260.15 × 147.5 (H×V) |
| behandeling | Glare (Haze 0%) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 35 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 262K 48% NTSC |
| agterlig | WLED , 15K hours , With LED Driver |
| omtrek vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruik vir | Laptop |
| herlaaitempo | 60Hz |
| raakskerm | In-Cell Touch |
| sein tipe | eDP (1 Lane) , HBR1 (2.7G/lane) , Connector 40 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
