| Onderdeel nommer | LMS700KF05 |
| Handelsmerk | Samsung |
| Grootte | 7.0 |
| Toepassing | MP4 |
| Resolusie | 800×480 |
| Samestelling | LCM |
| Helderheid | 350 |
| CR | 400:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | SAMSUNG |
| paneel model | LMS700KF05 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 7.0 inch |
| resolusie | 800×480(RGB) , WVGA |
| vertoonmodus | TN, Normally White, TMR |
| aktiewe area | 152.4×91.44 mm |
| buitelyn | 163.2×104×3.6 mm |
| oppervlak | |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 400 : 1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kykhoek | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 8S3PWLEDWithout Driver |
| sein koppelvlak | Parallel RGB (1 ch, 8-bit), 40 pins |
| insetspanning | 3.3V (Typ.)(VCC) |
| aansoek | MP4 |
| A070VW05 V2 | AUO | 7.0 | 800×480 |
| LMS700JF01-001 | Samsung | 7.0 | 1024×600 |
| LMS700JF04-0 | Samsung | 7.0 | 1024×600 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| LMS700KF05 | Samsung | 7.0 | 800×480 |
| LMS700KF06 | Samsung | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LMS700KF15 | Samsung | 7.0 | 800×480 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LMS700KF23 | Samsung | 7.0 | 800×480 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070ND28CW | CPT | 7.0 | 1024×600 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LMS430HF11 | Samsung | 4.3 | 480×272 |
| LMS700JF04-0 | Samsung | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
