| Onderdeel nommer | LMS480JC01 |
| Handelsmerk | Samsung |
| Grootte | 4.8 |
| Toepassing | PND |
| Resolusie | 1024×600 |
| Samestelling | LCM |
| Helderheid | 280 |
| CR | 350:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | SAMSUNG |
| paneel model | LMS480JC01 1 Compatible model |
| paneel tipe | LTPS TFT-LCD , LCM |
| paneel grootte | 4.8 inch |
| resolusie | 1024(RGB)×600 , WSVGA |
| vertoonmodus | TN, Normally White, TMR |
| aktiewe area | 104.45×61.2 mm |
| buitelyn | 112.05×73.26 mm |
| oppervlak | |
| helderheid | 280 cd/m² (Typ.) |
| kontras verhouding | 350 : 1 (Typ.) |
| kleure vertoon | 262K (6-bit), CIE193150% |
| reaksie tyd | 28 (Typ.)(Tr+Td) |
| kykhoek | 65/65/55/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 75Hz |
| tipe lamp | 5S1P+6S1PWLEDWithout Driver |
| sein koppelvlak | LVDS (1 ch, 6-bit), 28 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | PND |
| 35HVF0H | SII | 3.5 | 320×480 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| LQ036T1DG01 | SHARP | 3.6 | 272×480 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PD035VX2 | E Ink | 3.5 | 640×480 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
