| Onderdeel nommer | LM290WW2-SSD1 |
| Handelsmerk | LG Display |
| Grootte | 29.0 |
| Toepassing | Desktop Monitor Indu |
| Resolusie | 2560×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 18S4P |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LM290WW2-SSD1 |
| paneel grootte | 29.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 2560(RGB)×1080, CSHD, 96PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 672.768(W)×283.824(H) mm |
| ring opening | - |
| omtrek grootte | 693.6(W)×308.9(H) ×17.5(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| kleure vertoon | 16.7M 99% sRGB |
| tipe lamp | 18S4P WLED , 30K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 3.11/3.265Kgs (Typ./Max.) |
| aansoek | Desktop Monitor Industrial Medical Imaging |
| sein koppelvlak | LVDS (4 ch, 8-bit) , 92 pins Connector |
| insetspanning | 10.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
