| Onderdeel nommer | LM270WF7-SLD1 |
| Handelsmerk | LG Display |
| Grootte | 27.0 |
| Toepassing | Desktop Monitor Indu |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LM270WF7-SLD1 |
| skerm grootte | 27.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 81PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 597.888 × 336.312 (H×V) |
| buitelyn (mm) | 611.5 × 355.8 (H×V×D) |
| ring area (mm) | 601.5 × 339.95 (H×V) |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | WLED , 30K hours , No Driver |
| massa | 2.87/3.01Kgs (Typ./Max.) |
| gebruik vir | Desktop Monitor Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF3-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLN2 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SLB1 | LG Display | 27.0 | 2560×1440 |
