| Onderdeel nommer | LM190E0A-SLD1 |
| Handelsmerk | LG Display |
| Grootte | 19.0 |
| Toepassing | Desktop Monitor Digi |
| Resolusie | 1280×1024 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | LG Display |
| model | LM190E0A-SLD1 |
| diagonale grootte | 19.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×1024 [SXGA] 86PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 376.32(H)×301.056(V) mm |
| buitelyn dof. | 396(H)×324(V) ×10.4(D) mm |
| ring area | 378.8(H)×303.0(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 14 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED [19S2P] , 30K hours , W/O Driver |
| gewig | 1.46/1.54Kgs (Typ./Max.) |
| ontwerp vir | Desktop Monitor Digital Signage |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
