| Onderdeel nommer | LM150X08-TLB1 |
| Handelsmerk | LG Display |
| Grootte | 15.0 |
| Toepassing | DMPC |
| Resolusie | 1024×768 |
| Samestelling | LCM |
| Helderheid | 250 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | CCFL |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG.Philips LCD |
| paneel model | LM150X08-TLB1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 15.0 inch |
| resolusie | 1024(RGB)×768 , XGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 304.128×228.096 mm |
| buitelyn | 326.5×253.5×11.7 mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193160% |
| reaksie tyd | 2/6 (Typ.)(Tr/Td) |
| kykhoek | 70/70/65/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| tipe lamp | 2 pcsCCFLWithout Driver |
| sein koppelvlak | LVDS (1 ch, 8-bit), 20 pins |
| insetspanning | 3.3V (Typ.) |
| aansoek | DMPC |
| G150XTN04.0 | AUO | 15.0 | 1024×768 |
| G150XTT01.0 | AUO | 15.0 | 1024×768 |
| LM150X06-A3M2 | LG Display | 15.0 | 1024×768 |
| LM150X06-A4C4 | LG Display | 15.0 | 1024×768 |
| LM150X07-B4 | LG Display | 15.0 | 1024×768 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM150X08-TL01 | LG Display | 15.0 | 1024×768 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| CLAA185WA04 | CPT | 18.5 | 1366×768 |
| HT190WG1-600 | BOE | 19.0 | 1440×900 |
| LM220WE1-TLB3 | LG Display | 22.0 | 1680×1050 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LM300WQ5-SDA1 | LG Display | 30.0 | 2560×1600 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL12876AC39-01 | NLT | 23.0 | 1280×768 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
