| Onderdeel nommer | LM140LF3L |
| Handelsmerk | PANDA |
| Grootte | 14.0 |
| Toepassing | Laptop |
| Resolusie | 1920×1080 |
| Samestelling | Oxide TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | PANDA |
| paneel model | LM140LF3L (NCP0035) |
| paneel grootte | 14.0" |
| paneel tipe | Oxide TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 157PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 309.312(W)×173.988(H) mm |
| ring opening | - |
| omtrek grootte | 315.81(W)×197.57(H) ×2.95(D) mm |
| oppervlak | Antiglare |
| helderheid | 250 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | FFS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| kleure vertoon | 16.7M 72% NTSC |
| tipe lamp | WLED , 15K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| vorm styl | Slim (PCBA Flat, T≤3.2mm) |
| aansoek | Laptop |
| sein koppelvlak | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
