| Onderdeel nommer | LM116LF3L02 |
| Handelsmerk | PANDA |
| Grootte | 11.6 |
| Toepassing | Pad & Tablet |
| Resolusie | 1920×1080 |
| Samestelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| vervaardiger | PANDA |
| model naam | LM116LF3L02 (NCP0000) |
| skerm grootte | 11.6 inch |
| tipe skerm | LCM , Oxide TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 190PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 256.32 × 144.18 (H×V) |
| buitelyn (mm) | 268 × 168 × 3 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 300 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | FFS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 100% sRGB |
| agterlig | WLED , 15K hours , With LED Driver |
| massa | 215g (Max.) |
| gebruik vir | Pad & Tablet |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
