| Onderdeel nommer | LK558Z3LA1P |
| Handelsmerk | Sharp |
| Grootte | 55.8 |
| Toepassing | Digital Signage |
| Resolusie | 2560×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1800:1 |
| Kleure | 1.07B |
| Agterlig | 20 |
| Koppelvlak | LVDS |
| vervaardiger | Sharp |
| model naam | LK558Z3LA1P |
| skerm grootte | 55.8 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 2560(RGB)×1080 49PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 1305.6 × 550.8 (H×V) |
| buitelyn (mm) | 1372 × 610 × 56.2 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (2H) |
| helderheid | 450 cd/m² (Typ.) |
| kontras verhouding | 1800 : 1 (Typ.) (TM) |
| kykhoek | 88/88/88/88 (Typ.)(CR≥10) |
| reaksie | 4 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ASV, Normally Black, Transmissive |
| kleurdiepte | 1.07B 74% NTSC |
| agterlig | 20 pcs CCFL , 60K hours , With Inverter |
| massa | 16.9±1.0Kgs |
| gebruik vir | Digital Signage |
| herlaaitempo | 120Hz |
| raakskerm | Without |
| sein tipe | LVDS (4 ch, 10-bit) , 92 pins Connector |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
