| Onderdeel nommer | LD860DBN-UJA2 |
| Handelsmerk | LG Display |
| Grootte | 86 |
| Toepassing | Digital Signage Outd |
| Resolusie | 3840×600 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1100:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | V-by-One |
| handelsmerk | LG Display |
| model | LD860DBN-UJA2 |
| diagonale grootte | 86 inch (Native bar) |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 3840(RGB)×600 45PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 2148.48(H)×335.7(V) mm |
| buitelyn dof. | 2158.3(H)×348.5(V) ×82.2(D) mm |
| ring area | 2149.5(H)×336.7(V) mm |
| behandeling | Antiglare (Haze 10%), Hard coating (3H) |
| helderheid | 700 cd/m² (Typ.) |
| kontras verhouding | 1100:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 1.07B 98% sRGB |
| Ligbron | WLED , 50K hours , With LED Driver |
| gewig | 15.04Kgs (Typ.) |
| ontwerp vir | Digital Signage Outdoor High Brightness Stretched Bar LCD |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | V-by-One 8 lane , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
