| Onderdeel nommer | LD550DUN-TKH1 |
| Handelsmerk | LG Display |
| Grootte | 55 |
| Toepassing | Video Wall |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 1.06B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LD550DUN-TKH1 |
| paneel grootte | 55" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 40PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1209.6(W)×680.4(H) mm |
| ring opening | 1209.9(W)×680.7(H) mm |
| omtrek grootte | 1213.4(W)×684.2(H) ×57.2(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H), Antireflection |
| helderheid | 1500 cd/m² (Typ.) |
| kontras verhouding | 1300:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | S-IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kleure vertoon | 1.06B 72% NTSC |
| tipe lamp | WLED , 60K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| videomuur naat | 3.8 mm (active to active seam) |
| aansoek | Video Wall |
| sein koppelvlak | LVDS (2 ch, 10-bit) , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
