| Onderdeel nommer | LD320DPY-SKA1 |
| Handelsmerk | LG Display |
| Grootte | 32.0 |
| Toepassing | Transparent Display |
| Resolusie | 19203×1080 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel model | LD320DPY-SKA1 |
| paneel grootte | 32.0" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 1920(3)×1080, FHD, 69PPI |
| pixel formaat | RGBW Vertical Stripe |
| vertoon area | 698.4(W)×392.9(H) mm |
| ring opening | - |
| omtrek grootte | 714(W)×411(H) ×1.4(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H), Reflection 2.0% (Max.) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 9 (Typ.)(G to G) |
| glas diepte | - |
| deurlaatbaarheid | 8.63% (Typ.)(with Polarizer) |
| kleure vertoon | 16.7M |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COFBuilt-in 6 source chips |
| paneel gewig | 880g (Typ.) |
| aansoek | Transparent Display |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
