| Onderdeel nommer | LC650EQC-SPA1 |
| Handelsmerk | LG Display |
| Grootte | 65 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | EPI |
| paneel handelsmerk | LG Display |
| paneel model | LC650EQC-SPA1 |
| paneel grootte | 65" |
| paneel tipe | a-Si TFT-LCD, CELL |
| resolusie | 3840(RGB)×2160, UHD, 68PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1428.48(W)×803.52(H) mm |
| ring opening | - |
| omtrek grootte | 1440.3(W)×817.9(H) ×1.2(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1300:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 8/10 (Typ.)(Tr/Td) |
| glas diepte | - |
| deurlaatbaarheid | 5.51% (Typ.) |
| kleure vertoon | 1.07B 73% NTSC |
| tipe lamp | No B/L |
| frekwensie | 60Hz |
| raakskerm | Without |
| bestuurder ic | COF Built-in 12 source chips |
| paneel gewig | 3.20/3.36Kgs (Typ./Max.) |
| aansoek | TV Sets |
| sein koppelvlak | EPI , 120 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
